SMZ445 / SMZ460
Premium performance in a compact body.
The SMZ445 and SMZ460 deliver the outstanding optical performance you expect from Nikon's cutting-edge series of stereoscopic zoom microscopes. Porro prisms enable a lightweight, compact design. With 0.8x - 3.5x zoom magnification (SMZ445) and 0.7x - 3.0x zoom magnification (SMZ460), and diascopic/episcopic LED Stand, the SMZ445 and SMZ460 let you observe a wide range of specimens, from Petri dishes to plants, insects, small animals and minerals.
- Outstanding Optical Performance: High quality images with superior flatness are achieved by following the optical design and quality criteria of all Nikon's high performance stereoscopic microscope series. The multicoatings on lens surfaces provide clear, bright and high contrast images.
- Long Working Distances: The long working distance of 100mm allows safe focusing even with specimens having markedly uneven surfaces. This is useful when using tweezers, dissection tools or a pipette during specimen manipulation.
- Eyepiece Lenses: Dedicated eyepiece lenses with diopter adjustments for parfocality. Combining the SMZ445 with 20x eyepiece lenses enables observation at a maximum of 70x. Rubber eyecups are available for the 10x eyepiece lenses.
- Auxiliary Objectives: Simply attaching an auxiliary objective lens achieves a wider field of view and longer working distance. Two types are available, 0.5x (WD 181mm) and 0.7x (WD 127.5mm).
- Mold-Resistant Finish: The inside of the zooming body is treated with a mold-resistant finish. This maintains the quality of the lenses even in hot, humid environments.
SMZ460
- Type: Greenough
- Eyepiece: SM 10xB eyepieces (F.N. 21)
- Zoom range: 0.7x ~ 3x (Zoom ratio: 4.3:1)
- Auxiliary objective lens: AL0.5x, 0.7x (optional)
- Working distance: 100mm (standard configuration)
- Eyepiece inclination: 60º
- Optical system: True erect image, 12º inner bevel, independent adjustment of right and left eyepieces, and 54 to 75mm interpupillary adjustment
- Weight (Zooming body): Approx. 1.0kg
