Astronomy > Mounts & accessories > Mounts > Equatorial with GoTo > iOptron > iEQ30 > iOptron iEQ30 Pro GEM mount with a tripod
Product no.: 26775

iEQ30 Pro GEM mount with a tripod

RRP: $ 1,670.00 Our price:
$ 1,650.00 incl. VAT plus shipping costs
too expensive?
long-term
Product not available anymore + lead time

No delivery possible before Christmas. Order a voucher coupon!


Product description

Introducing the NEW iEQ30 Pro!--- the next in the iEQ Series of high-performance, portable equatorial mounts

The iEQ30 Pro offers the next generation GoTo technology from iOptron®. It come standard with a calibrated dark field illumination polar scope, built-in GPS, and sturdy stainless steel tripod legs. Plus, it offers premium performance in an easy-to-transport package.

  • Updated with more advanced control electronics
  • Ultra quiet slewing and tracking
  • Higher gear ratio (RA 180 teeth | DEC 144 teeth)
  • 1.8 degree stepper motor, 128 microsteps
  • Resolution: 0.14 arc second
  • Permanent periodic error correction (PPEC)
  • Built-in 32-channel GPS
  • Hand controller with Advanced GOTONOVA® GoTo Technology and heating mechanism
  • Lowest working temperature: -20°C
  • Power interruption recovery feature
  • RS232 port for mount firmware upgrade and ASCOM control
  • ST-4 autoguiding port
  • heavy-duty stainless steel tripod legs
  • Die cast metal tripod spreader with accessory tray
  • AccuAlignTM polar scope with dark-field illumination and Quick Polar Alignment procedure, allowing for fast and accurate polar alignment
  • Comes standard with: 4.5kg counterweight, AC adaptor, 12V DC car plug adaptor, Stainless Steel counterweight shaft, RS232-RJ9 cable.

Specialized astrophotography mount ideal for entry-level and intermediate astrophotographers

Specifications

Capacity


Type
Equatorial
Designation
iEQ30 Pro GEM
Max. additional load capacity (kg)
14
Language
English
Worm gear teeth (RA) (piece)
180
Interfaces
Autoguider, RS-232
Software
Go2Nova 8407
Precision of tracking
0,14
Weight (g)
6800
Counterweight(s) (piece)
1 (4,5kg)
Polar elevation setting (°)
0 - 65
Diameter of counterweight bar (mm)
20
Power supply
12 (DC12V/2A)
Power consumption (mA)
400 - 600
Database
359.000
Operating temperature
-20 - +45
Material of worm gear
Aluminium
Diameter (mm)
120 (Mount base diameter)
Motor speeds
9 speeds, max 6°/s
DEC ball bearings diameter (mm)
55
RA ball bearings diameter (mm)
68
RA axis diameter (mm)
40
DEC worm gear diameter (mm)
88
DEC axis diameter (mm)
30
Material of worm wheel
Aluminium
RA worm gear diameter (mm)
110
DEC worm shaft diameter (mm)
15,2
RA worm shaft diameter (mm)
15,2
Worm gear teeth (DEC) (piece)
144

Special features


GoTo system
yes
GPS
yes
Pole finder
yes (illuminated)
PEC correction
yes (permanent)
Handcontroller
yes
Level
yes
PC interface
yes (RS232-RJ9 cable)
Controllable via PC
yes (ASCOM)
Fitting for prism rail
yes (Vixen-Style)
Traveling mount
yes

Tripod


Tripod weight (kg)
4,8
Tripod material
Steel
Max. tripod height (cm)
112
Durchmesser der Stativbeine (mm)
38,1

General


Series
iEQ30
Total weight (kg)
12

Area of application


Autoguider
yes
Useful for photographs
yes
